Description du produit « WALKSNAIL - AVATAR VRX + KIT VTX AVATAR »
Note:
- Les envois des Kit VRX + VTX sont pévus pour le 10 Décembre 2022
- Vous pouvez demander un remboursement à tout momement durant la période de pré-commmande et avant le 30 novembre 2022
- Les prix comprennent les frais de ports, la tva et les frais de douanes
| Specification | |
| Camera | |
| Model | Avatar nano/Avatar camera |
| Image Sensor | 1/2.7”1nch |
| Resolution | 1080P/60fps,720P/120fps,720P/60fps |
| Ratio | 16/9 4/3 |
| Lens | 2.1mm |
| FOV | 170° |
| Aperture | F2.0 |
| Shutter | Rolling shutter |
| Min.Illumination | 0.001Lux |
| Weight | 3.5g/6g |
| Dimensions | 14*14*17mm/19*19*22mm |
| Coaxial Cable | 90mm/140mm |
| VTX | |
| Model | Avatar module |
| Communication Frequency | 5.725-5.850GHz |
| Transmitter Power (EIRP) | FCC: MIC: |
| 1/O Interface | JST1.0*6(Power in)JST1.0*4(USB) |
| Mounting Holes | 25.5*25.5mm |
| Dimensions | 33*33*9.5mm |
| Storage | 8G |
| Recording | 1080p/720p |
| Weight | 16g |
| Operating Temperature | -20-40℃ |
| Channels | 8 |
| Wide Power Input | 6V-25.2V |
| Supported FC System | Betaflight |
| OSD | Canvas mode |
| Latency | Average delay 22ms |
| Antenna | 2(IPEX) |
| Goggles Antenna | |
| Model | Red bird |
| Polarization | LHCP |
| Bandwidth | 5.6GHz-6.0GHZ |
| Average Gain | 1.9dBi |
| Radiation Efficiency | ≥97% |
| VSWR | ≤1.3 |
| Cross-Polar Rejection | -15to-30dB |
| Connector | RP-SMA |
| Dimension | H24.8mm*R15.3mm |
| Weight | 4.2g |
| Avatar HD VRX | |
| Model | Avatar HD VRX |
| CommunicationFrequency | 5.725-5.850GHz |
| TransmitterPower(EIRP) | FCC: |
| I/OInterface | HDMI,microSDcardslot,DC5.5*2.1mm |
| HDMIOutput | 1080p60fps,720p100fps,720p60fps |
| PowerInput | 7-21V(2S-5S) |
| SDCard | Support256G |
| System | AvatarHDsystem |
| Packing List | |
| Avatar VRX | ×1 |
| RedBirdAntenna | ×2 |
| HDMICable | ×1 |
| 2in1DCPowerCable | ×1 |
| Avatar HD KIT | X1 |
| 4 Pin USB Cable | X1 |
| 6 Pin Power Cable | X1 |
| M2x3/4/5mm Screws | X4 |
| M1.2x1.5mm Screws | X2 |
| Avatar HD Nano KIT | X1 |
| 4 Pin USB Cable | X1 |
| 6 Pin Power Cable | X1 |
| M2x3/4/5mm Screws | X2 |
| M1.2x1.5mm Screws | X2 |
| 14-19mm Bracket | X1 |
| Avatar Mini 1S KIT | X1 |
| 4 Pin USB Cable | X1 |
| 6 Pin Power Cable | X1 |
| M2x3/4mm Screws | X2 |
| M2x16mm Screws | X4 |
| M2 Screw nut | X4 |
| 2.1x3.4x1mm Gasket | X5 |
Q&A
Q:Is VRX compatible with goggles from other products?
A:Compatible With Analog Goggles,HDMI Out(Our VRX module supports hdmi out, if your glasses support hdmi in it should work)
Q:Do i need a set of goggles with a 1080p resolution or an 720p is enough?
A:VRX supports 720P\1080P
Q:Avatar HD Micro kit come with a 140mm cable between the VTX and camera?
A: yes
Q:does the Pre-sale unit fit 20x20 mount?
A:Our vtx is 25*25
Q:the difference between all 3 of the walksnail kits? What is the Avatar 1s vs avatar hd micro vs avatar HD nano?
A:
mini 1s kit
350mw, Power Input: 3.1V-5V, VTX Weight 6.8g
avatar HD micro/nano kit standard version
1200mw, Power Input: 6V-25.2V, VTX Weight: 16g
Q:Micro/Nano Camera difference?
A:
Weight：3.5g/6g
Dimensions：14*14*17mm/19*19*22mm
Coaxial Cable：90mm/140mm
